| MODEL | VT-DO 500 |
|---|---|
| Temperature Range | RT ~ 250°C (It can raise the temperature further by customer order) |
| Dimension(WxDxH)In (Room Capa.) ℓ | 12000 x 1200 x 400mm (It can be extended by customer order.) |
| Dimension(WxDxH) Out | 15000 x 1800 x 1700mm (It can be extended by customer order.) |
| Material In | SUS 304 |
| Material Out | Steel Plate Painting |
| Temperature Control | Digital P.I.D. Control |
| Temperature Sensor | CA |
| Temperature Accuracy | ±0.1°C |
| Temperature Stabiltiy | ±1.0°C |
| Temperature Uniformity | ±5.0°C |
| Rate of temperature rise per min. | 3.0°C |
| Insulation | Ceramic wool 150mm |
| Motor | 1HP x 8ea |
| Method | Forced Convection Oven (Phương pháp thổi cưỡng bức) / Forced Air Circulation |
| Heater Capa | Electric SUS Heater (13.5Kw x 8) |
| Conveyor Speed Range | 2~4 h / 15m |
| Circulation | - |
| Recording System | Select Option |
| Door | Left and Right Pulling Door (2 Door) |
| Propeller Fan | (Ø800 x 4B) x 8ea |
| Safety Device | 1. ELB (Earth Leakage Breaker)
2. OHP (Over Heating Protective Device)
3. EOCR (Electronic Over Current Relay) 4. NFB (No Fuse Breaker) 5. RPR (Rverse Phase Relay) 6.Emergency S/W |
| Accessory | Timer Buzzer A-mater Signal Lamp (3 colors) x 2set |
| Specialties (Select Option) | 1. Special dimensions can be ordered separately by the customer. (Test Chamber Size)
2. Special Temp. can be ordered separately by the customer. (Test Temp. Range) |
| * Hình thức và thông số kỹ thuật có thể được thay đổi để cải thiện hiệu suất của thiết bị.
* External appearance & type and specifiation may be to change without advance notice to enhance the performance of equipment. | |
