| MODEL | VT-DO 300 |
|---|---|
| Temperature Range | RT ~ 250°C (It can raise the temperature further by customer order) |
| Dimension (WxDxH) In (Room Capa.) ℓ | (700 x 800 x 1250mm) x 2Rooms (700ℓ x 2Rooms) |
| Dimension (WxDxH) Out | 2500 x 1100 x 2200mm |
| Material In | SUS 304 |
| Material Out | Steel Plate Painting |
| Temperature Control | Digital P.I.D. Control |
| Temperature Sensor | CA |
| Temperature Accuracy | ±0.1°C |
| Temperature Stabiltiy | ±0.5°C |
| Temperature Uniformity | ±3.0°C |
| Rate of temperature rise per min. | 3°C |
| Insulation | Ceramic wool 150mm |
| Motor | (0.4Kw x 2set) x 2 Rooms |
| Method | Forced Convection Oven (Phương pháp thổi cưỡng bức / Forced Air Circulation) |
| Heater Capa | Electric Pipe Pin Heater (1.5Kw x 12sets) x 2Rooms |
| Shelves | - |
| Circulation | - |
| Recording System | Select Option |
| Door | Left and Right Pulling Door (2 Door) |
| Sirocco Fan | (8"x4"x2ea) x 2Rooms |
| Power Source / Power Consumption | 3ØAC220V or 380V 50/60Hz / 40Kw |
| Safety Device | 1. ELB (Earth Leakage Breaker)
2. OHP (Over Heating Protective Device)
3. EOCR (Electronic Over Current Relay) 4. NFB (No Fuse Breaker) 5. RPR (Rverse Phase Relay) 6. Emergency S/W |
| Accessory | Timer Buzzer A-mater Signal Lamp (3 colors) |
| Specialties (Select Option) | 1. Special dimensions can be ordered separately by the customer. (Test Chamber Size) 2. Special Temp. can be ordered separately by the customer. (Test Temp. Range) * Hình thức và thông số kỹ thuật có thể được thay đổi để cải thiện hiệu suất của thiết bị. * External appearance & type and specifiation may be to change without advance notice to enhance the performance of equipment. |
